自动配置中断和地址
16850 UART
自动门控,用于在多任务操作系统下有效地使用 RS-485 半双工模式
PCI Bus: High performance I/O slot in every desktop Pentium, Pentium (II) and Pentium Pro PC. PCI provides improved performance to all running applications by freeing up the CPU.PCI cards are detected and configured automatically by the PC, so avoiding conflicts in address and interrupts. PCI cards automatically implement a shared interrupt system so maximising use of precious system resources.,The Windows and DOS device drivers supplied with each serial card from RS reads the PCI assigned setup and configures your system accordingly.,All the serial boards in this range are Plug and Play, Windows 3.1; 95; 98; Me, NT, 2000; XP ,Vista and 7compatible and PCI 2.1 compliant.
属性 | 数值 |
---|---|
总线类型 | PCI |
通信接口 | 串行 |
端口数目 | 2 |
连接端口 | RS422, RS485 |
最大波特率 | 921.6kbit/s |
FIFO 尺寸 | 128 B |
